CDCS P81 Series

TYPE
TECHNICAL DATA CDCS 630 P81 CDCS 800 P81 CDCS 1100 P81 CDCS 1300 P81
Capacity tons 63 80 110 130
Nominal tonnage height mm 4,5 4,5 5 6
Max. closed mold height mm 350 385 385 385
Stroke setup mm 4/102 4/102 14/114 5/110
Strike number per minute spm 54 54 60 60
Mold fitting seat diameter mm 50 50 50 65
Neck depth mm 270 280 280 330
Hammer size mm 90 (Manuel) 90 (Manuel) 90 (Manuel) 90 (Manuel)
Hammer setup mm 490x325 490x325 490x325 630x400
Table size mm 750x500 900x540 900x540 1000x640
Table hole diameter mm 170 180 180 180
Table height from the ground mm 765 750 790 210
Estimated press weight kg 4100 5400 5600 780
Estimated press height mm 2750 2750 2800 3000
Estimated press depth mm 1800 2010 1870 3000
Estimated press width mm 1150 1390 1320 1372
Motor power kw 7,5 7,5 7,5 11
Stroke system - Manuel Adjustable Manuel Adjustable Manuel Adjustable Manuel Adjustable
Overload safety system - Mechanical Mechanical Mechanical Mechanical
Centralized lubrication system - Automatic Grease Automatic Grease Automatic Grease Automatic Grease
Clutch brake system - Pneumatic Pneumatic Pneumatic Pneumatic
Safety guard system - Photo-cell Photo-cell Photo-cell Photo-cell
Vibration pads - Standard SStandard Standard Standard
Speed control unit - Optional Optional Optional Optional
Additional plate - Optional Optional Optional Optional
* Our right to change the sizes and models is reserved.
TYPE
TECHNICAL DATA CDCS 1600 P81 CDCS 2000 P81 CDCS 2500 P81
Capacity tons 160 200 250
Nominal tonnage height mm 6 6 6
Max. closed mold height mm 480 440 500
Stroke setup mm 15/110 24/140 24/140
Strike number per minute spm 60 50 50
Mold fitting seat diameter mm 65 65 65
Neck depth mm 350 390 430
Hammer size mm 95 (Motorlu) 100 (Motorlu) 100 (Motorlu)
Hammer setup mm 630x400 950x600 950x600
Table size mm 1100x700 1200x740 1250x850
Table hole diameter mm 210 220 240
Table height from the ground mm 810 820 825
Estimated press weight mm 9950 14900 16800
Estimated press height mm 3200 3435 3550
Estimated press depth kw 2400 2350 2400
Estimated press width mm 1430 1700 1707
Motor power kw 15 15 18,5
Stroke system - Manuel Adjustable Manuel Adjustable Manuel Adjustable
Overload safety system - Mechanical Hidrolik Mechanical
Centralized lubrication system - Automatic Grease Automatic Grease Automatic Grease
Clutch brake system - Pneumatic Pneumatic Pneumatic
Safety guard system - Photo-cell Photo-cell Photo-cell
Vibration pads - Standard Standard Standard
Speed control unit - Optional Optional Optional
Additional plate - Optional Optional Optional
* Our right to change the sizes and models is reserved.
