CDCS P81/L Series

TYPE
TECHNICAL DATA CDCS 601 P81/L CDCS 801 P81/L CDCS 1001 P81/L
Capacity tons 60 80 100
Rated tonnage point mm 2 4 4
Max. closed die set height mm 365 350 350
Stroke distance mm 35 35 35
Press speed spm 100-270 100-270 100-270
Die hole diameter mm 45 45 50
Throat debth mm 270 255 305
Ram adjustment mm 90 (Motorlu) 90 (Manuel) 95 (Manuel)
Ram dimension mm 490x325 490x325 490x325
Table dimension mm 750x500 860x540 860x540
Table hole diameter mm 180 190 190
Table height from the ground mm 770 810 800
Estimated press weight kg 4700 5400 6000
Estimated press height mm 2270 2370 2416
Estimated press depth mm 1920 2070 2070
Estimated press width mm 1100 1100 1210
Motor power kw 7,5 11 15
Stroke system - Fixed Fixed Fixed
Overload safety system - Hydraulic Hydraulic Hydraulic
Centralized lubrication system - Re-cycle automatic Re-cycle automatic Re-cycle automatic
Clutch brake system - Pneumatic Pneumatic Pneumatic
Die area safety system - Mechanical Mechanical Mechanical
Vibration pads - Standard Standard Standard
Speed control unit - Standard Standard Standard
Additional plate - Optional Optional Optional
* Our right to change the sizes and models is reserved.
