CDHC Series

TYPE
TECHNICAL DATA CDHC 630-400-250 CDHC 1000-400-400 CDHC 1600-400-630 CDHC 2000-400-630
Capacity tons 63 100 160 200
Cushion capacity tons 25 40 63 63
Stroke distance mm 400 400 400 400
Cushion stroke distance mm 150 150 150 150
Table dimension spm 750x615 850x640 1000x750 1090x855
Max. distance between table and ram mm 630 685 765 785
Work speed mm/s 10-25 10-20 10-20 16
Rapid approach speed mm/s 300 250 250 200
Estimated press weight kg 4900 7700 10500 14000
Estimated press height mm 3170 3565 3900 3910
Estimated press depth mm 1710 2030 2400 2510
Estimated press width mm 1150 3350 3800 3910
Height of the press mm 1680 1150 1525 1525
Motor power kw 7,5 11 22 30
Centralized lubrication system - Aoutomatic grease Aoutomatic grease Aoutomatic grease Aoutomatic grease
Die area safety system - Photo-cell Photo-cell Photo-cell Photo-cell
Additional plate - Optional Optional Optional Optional
* Our right to change the sizes and models is preserved.
