CDHH Series

TYPE
TECHNICAL DATA CDHH 200-700-800 CDHH 2500-800-1600 CDHH 300-800-1600 CDHH 400-1000-00 CDHH 4000-700-800
Capacity tons 200 250 300 400 400
Cushion capasity tons 80 160 160 - 80
Stroke distance mm 700 800 800 1000 700
Cushion Stroke distance mm 300 355 440 - 350
Table dimension mm 1600x1200 1200X1100 1400X1200 2000X1600 1600X1300
Max. distance between table and rame mm 950 1300 1300 1600 1140
Table height from the ground mm 900 1200 1180 1000 1200
Working speed mm/sn 10-20 35-62 35-95 10-35 10-35
Rapid approach speed mm/sn 200 540 200 200 200
Estimated press weight kg 25000 28600 32360 50000 42000
Estimated press height mm 4650 5680 5600 6450 6049
Estimated press depth mm 2240 5250 6500 6500 2900
Estimated press width mm 3240 4200 4000 4200/2980 4340
Motor power kw 15 22 55 160 75
Centralized lubrication system - Automatic Grease Automatic Grease Automatic Grease Automatic Grease Automatic Grease
Die area safety system - Photo-cell Photo-cell Photo-cell Photo-cell Photo-cell
Additional plate - Optional Optional Optional Optional Optional
* Our right to change the sizes and models is reserved.

TYPE
TECHNICAL DATA CDHH 5000-140-00 CDHH 7500-600-1000 CDHH 8000-400-00 CDHH 12000-1050-3000 CDHH 15000-600-3000
Capacity tons 500 750 800 1200 15000
Cushion capasity tons - 100 - 300 300
Stroke distance mm 140 600 400 1050 600
Cushion Stroke distance mm - 360 - 400 225
Table dimension mm 1400x700 1400X1400 1000X1000 1300X1300 1400x1400
Max. distance between table and rame mm 340 1200 780 1500 1140
Table height from the ground mm 900 1000 940 950 1000
Working speed mm/sn 10-20 10-45 10-20 10-20 10-45
Rapid approach speed mm/sn 200 480 200 200 480
Estimated press weight kg 24000 82000 86000 93000 103000
Estimated press height mm 4000 6850/4130 4250 7611/7396 6300/2280
Estimated press depth mm 2950 6800/6800 2340 4100/3087 7410/7200
Estimated press width mm 3550 4520/3290 2970 4300/3335 4600/2850
Motor power kw 37 2x110 45 110 4x110
Centralized lubrication system - Automatic Grease Automatic Grease Automatic Grease Automatic Grease Automatic Grease
Die area safety system - Photo-cell Photo-cell Photo-cell Photo-cell Photo-cell
Additional plate - Optional Optional Opsiyonel Optional Optional
* Our right to change the sizes and models is reserved.
