CDCK PMU 2 Series

TYPE
TEKNİK BİLGİLER CDCK 3150
PMU 2
CDCK 4000
PMU 2
CDCK 5000
PMU 2
CDCK 6300 PMU 2 CDCK 8000
PMU 2
Capacity ton 315 400 500 630 630 800
Rated tonnage height mm 6 8 8 5 10 10
Max. closed mold height mm 600 850 860 550 700 700
Stroke distance mm 160 250 250 80 250 250
Press speed spm 30-50 30-50 30-50 60-80 30-50 30-50
Motorized ram adjuctment mm 150(motorized) 150(motorized) 150(motorized) 140(motorized) 200(motorized) 200(motorized)
Table dimension mm 1800x1200 1800x1200 1800x1200 1600x1200 2500x1400 2500x1400
Number of connecting rod piece 2 2 2 2 2 2
Table height from the ground mm 900 1020 1029 980 1040 1100
Estimated press weight kg 35000 40500 43500 58000 62000 110000
Estimated press height mm 5750 5850 5650 6150 7500 8000
Estimated press depth mm 2300 2400 2190 4500 5500 5700
Estimated press width mm 3300 3480 4210 2900 3100 3300
Motor power kw 45 55 55 55 75 75
Stroke system - Fixed Fixed Fixed Fixed Fixed Fixed
Overload safety system - Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic
Centralized lubrication system - Re-cycled liquid Re-cycled liquid Re-cycled liquid Re-cycled liquid Re-cycled liquid Re-cycled liquid
Clutch brake system - Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic
Die area safety system - Photo-cell Photo-cell Photo-cell Photo-cell Photo-cell Photo-cell
Vibration pads - Standard Standard Standard Standard Standard Standard
Speed control unit - Standard Standard Standard Standard Standard Standard
Additional plate - Optional Optional Optional Optional Optional Optional
* Our right to change the sizes and models is reserved.
